Gilding - paper, leather, wood, plastic,
-
Baked - wood products, baked painting, gift box packaging;
-
Embossing - paper, leather, cloth.
-
Flat-object stamping machine with large-pressure, Suitable for stamping on invitation letter, card. Leather, wooden gift, Paper package, Plastics film, Electron products;
-
Manual. Automatic feed foil, automatic temperature controlling ensures stamping quality.
-
Because of large pressure, It is suitable for gilding and baking Impression on leather, paper, wooden materials.
-
Pneumatic drive, pressure large.
Application fields
-
Paper Gilding, Leather Impression, Wood ware Baking
-
Paper Concave-convex embossing, Cloth hot stamping,
-
Plastics Bronzing
-
Mobile screen, Household appliances Panel , Thick paper card, PVC board Etc. large dimension Flat substrate stamping and Bronzing.
-
Woodiness objects baking-burns and Impress;
-
Leather bronzing and Molding;
-
Paper products concavo indentation.
-
Graduated disc of clock bronzing.
Pneumatic hot stamping Machine //Parameter
H-TC1015R4R
-
Hot plate area:100× 150 mm
-
Working table area: R500mm
-
Max printing pressure:1,000-1500 Kg
-
Up and down distance:100mm
-
Heat wattage:2500W
-
Foil in feed: Motor Drive
-
Temperature adjustment:0-300oC .
H-TC1927R4R
-
Hot plate area:190 × 270 mm
-
Working table area: R500mm
-
Max printing pressure:1000-1500 Kg
-
Up and down distance:100mm
-
Heat wattage:2500W
-
Foil in feed: Motor Drive
-
Temperature adjustment:0-300oC
Works supply:110V-220VPower supply;5-7Bar compress air
Package size: . 0.770×0.820×1.550mm
Gross weight: 220kg
CBM: 1.0145
H.S.Code: 8443198000
Certificate: CE
Pneumatic hot stamping machine with servo working table //Advantage
-
Table can be pulled into and pulled out the pick and place of convenience products;
-
Table can be up and down, around, before and after the precision adjustment, to facilitate the adjustment of the precise location of the gilt;
-
Table lifting screw adjustment, simple and convenient;
-
Relays for process control, stable operation, easy maintenance;
-
The use of advanced temperature control system, the temperature can be set freely, high precision temperature control, with automatic temperature control;
-
leveraged cylinder pressure, the pressure is uniform and strong;
-
The basic parameters of the hot stamping process; temperature, pressure, hot pressure, the rolls of time in accordance with the process requirements of the flexible adjustment;
-
Motor to control the delivery of the gold foil paper, resin length can be flexibly adjusted according to the size of the stamping area;
-
Using high strength steel, gilt plate and table, has a very high flatness;
-
Heating tube for heating, heat supply is stable, easy to replace
|
